3-WAY BALL VALVE ‘T’ PORT Bottom Entry Chrome Plated Brass
91 .85
$91.85 - $522.503-Way Ball Valve T Port Bottom Entry Chrome Plated Brass
Suited to diverting or combining flow paths in water, air and general service systems. The T port configuration allows multiple flow options, and the nickel plated brass body provides steady performance in industrial and workshop environments.
Key Applications
- Flow diversion and mixing points
- General industrial manifolds
- Water and air service lines
Product Features
- T port flow configuration
- Bottom entry design
- Nickel plated brass body
- Chrome plated brass ball with PTFE seats
- Stainless steel handle and hardware
- Rated to 2500 kPa cold working pressure
- Maximum temperature 150 degrees C
Available Sizes
| Part No. | Description |
|---|---|
| BVTP10BE | 10mm 3-Way Ball Valve T Port Bottom Entry |
| BVTP12BE | 12mm 3-Way Ball Valve T Port Bottom Entry |
| BVTP20BE | 20mm 3-Way Ball Valve T Port Bottom Entry |
| BVTP25BE | 25mm 3-Way Ball Valve T Port Bottom Entry |
| BVTP32BE | 32mm 3-Way Ball Valve T Port Bottom Entry |
| BVTP40BE | 40mm 3-Way Ball Valve T Port Bottom Entry |
| BVTP50BE | 50mm 3-Way Ball Valve T Port Bottom Entry |
Performance and Reliability
The nickel plated brass body and chrome plated ball support reliable operation in diversion and mixing duties. The T port arrangement offers flexibility across a range of service lines, with smooth movement from the stainless steel handle assembly.
For any product enquiries, use our contact page.
Product Specifications
- Design
- T port 3-way ball valve with bottom entry design
- Usage
- Flow diversion, mixing points, water and air service lines
- Material
- Nickel plated brass body, chrome plated brass ball, PTFE seats, stainless steel handle
- Max pressure
- 2500 kPa cold working pressure
- Temperature range
- Up to 150 degrees C
