Screwed Brass Cap

A cap closes a male thread. It goes over the outside of a male port and seals it, which is what you need when a line has been decommissioned, a spare outlet has to be blanked, or a system is being pressure tested with one branch shut off.

Key features

• Female BSP thread, caps a male port
• Seals decommissioned and spare outlets
• Manufactured to AS 1722 and AS 3688
• Pressure rated to 3500 kPa (500 psi)
• Temperature range 0°C to +120°C
• BSP threads for local and international compatibility
• Cast or extruded brass for corrosion resistance

Applications

• Blanking spare outlets on a manifold
• Decommissioning a branch line
• Pressure testing with a branch isolated
• Fuel, oil and gas lines
• Water and lubrication systems

Compatibility and fitting

• A cap goes over a male thread; a plug goes into a female one
• Seal the thread properly: a blank that weeps is as much of a leak as anything else
• Seal tapered threads with tape or a sealant rated for the fluid you are carrying
• Brass into brass strips easily: tighten to seal, not to a hard stop
• Do not mix thread standards: a fitting cut to a different standard will start, feel tight and then weep

Cap or plug?

Look at the port. A male thread sticking out takes a cap over it. A female port takes a plug into it. Ordering the wrong one is the most common mistake with both.

Is it rated to the full system pressure?

Yes, to 3500 kPa like the rest of the range. A capped branch is still part of the pressurised system, so it needs to be sealed and tested like any other joint.

The full range is in brass fittings.
